Chapter 4: Chassis Setup and Maintenance
Figure 4-7. Securing the Rear Hard Drive Cage to the Chassis
1
5
1
6
1
4
5. Secure the top of the hard drive cage to the chassis frame with two screws,
fastened at the upper edge of the hard drive cage above the opening of the
hard drive cage.
6. Secure the back of the hard drive cage to the chassis with one screw as shown
above.
7. Replace the power cords and power up the server.
