5-8
SUPERSERVER 5018D-MHR7N4P User's Manual
Connector Description
JOH1 Overheat LED Header
JPH1 4-pin Power Connector for HDDs
JPI
2
C1 Power Supply SMBus I
2
C Header
JPV1 12V 8-pin Power Connector (provides alternate power for
special enclosure when the 24-pin ATX power is not in use)
JPW1 24-pin ATX Power Connector
JSD1, JSD2 SATA DOM (Device On Module) Power Connectors
JSMB1 SMBus Header
JSTBY1 5V Standby Power Header
JTGLED1 LAN7 ~ LAN8 Activity LED Header
JTPM1 Trusted Platform Module (TPM)/Port 80 Connector
LAN1, LAN2, LAN7,
LAN8
Gigabit Ethernet (RJ45) Ports (LAN1 ~ LAN2)
10Gigabit Ethernet (SFP+) Ports (LAN7 ~ LAN8)
L-SAS0 ~ L-SAS15 SAS 2.0/SATA 3.0 Ports
M2-SRW1 ~ SRW3 M.2 Mounting Screws
MP-SRW1 ~ SRW2 PCI-E 2.0 x1 / I-SATA5 Slot Mounting Screws
Slot6, Slot7 CPU PCI-E 3.0 x8 Slot
UID Unit ID Button
USB 0/1 Back Panel USB 3.0 Ports
USB 2 USB Type-A Connector
USB 3/4, 5/6 Front Access USB 2.0 Ports
VGA VGA Port
LED Description Color/State Status
LED3 Power LED Green: On System Power On
LED7 UID Switch LED Blue: On
LED8
Overheat/PWR Fail/Fan Fail
LED
Red: Solid on
Blinking
Overheat
PWR Fail or Fan Fail
LEDM1 BMC Heartbeat LED Green: Blinking BMC: Normal
LEDT1 LAN7 Link Status Green: On LAN7 Normal
LEDT2 LAN7 Activity Green: Blinking LAN7 Active
LEDT3 LAN8 Link Status Green: On LAN8 Normal
LEDT4 LAN8 Activity Green: Blinking LAN8 Active
To Next Page
