Chapter 5: Advanced Motherboard Setup
5-19
5-9 Onboard Indicators
LAN Port LEDs
The Ethernet ports have two LEDs. On
each port, one LED indicates activity
be green, amber or off to indicate the
speed of the connection. See the tables
on the right for more information.
ME Manufacturing Mode
-
curity and force the system to use the
Manufacturing Mode, which will allow
from a host server to modify system
settings. See the table on the right for
jumper settings.
Manufacturing Mode
Jumper Settings
Pins 1-2 Normal (Default)
Pins 2-3 Manufacturing Mode
BMC Heartbeat LED Status
Green: Blinking BMC: Normal
BMC Heartbeat LED
A BMC Heartbeat LED is located at
LEDM1. See the table on the right for
more information.
LAN Port Link Speed LED
Off No Connection or 10 Mbps
Amber 1 Gbps
Green 100Mps (10Gbps for 10GbE Port)
Overheat/PWR Fail/Fan Fail
LED Settings
Off No Connection
Yellow Flashing Active
Overheat/PWR Fail/Fan Fail LED
An onboard Overheat/PWR Fail/Fan
Fail LED is located at LED8. See the
table on the right for more information.
Onboard Power LED
An onboard Power LED is located at
LED3 on the motherboard. When this
LED is on, the system is on. Be sure
to turn off the system and unplug the
power cord before removing or install-
ing components. See the table on the
right for more information.
Onboard PWR LED Indicator
LED Settings
Off System Off (PWR cable
not connected)
Green System On
Overheat/PWR Fail/Fan Fail
LED Settings
Red Solid Overheat
Red Blinking Power Fail or Fan Fail
To Next Page
