Supermicro SUPERSERVER 5018D-MHR7N4P User Manual

5-18
SUPERSERVER 5018D-MHR7N4P User's Manual
BIOS Recovery
Close pins 2 and 3 of jumper JBR1 for
BIOS recovery. The default setting is on
pins 1 and 2 for normal operation. See
the table on the right for jumper settings.
BIOS Recovery
Jumper Settings

Pins 1-2 Normal
Pins 2-3 BIOS Recovery
BMC Enabled
JPB1 allows you to enable the BMC
(Baseboard Management Control) chip
and the onboard IPMI connection for
debugging purpose only. After the BMC
is disabled, IPMI health and remote
management functions are no longer
supported. See the table on the right for
jumper settings.
Note: Please always keep BMC enabled
to make sure that the platform operates
reliably with the health monitor.
BMC Enabled
Jumper Settings

Pins 1-2 Enabled (Default)
Pins 2-3 Disabled
10GbE LAN Ports Enable/Disable
JPTG1 is used to enable or disable
10GbE support. See the table on the
right for jumper settings.
10Gb Enable/Disable
Jumper Settings

Pins 1-2 Enabled (Default)
Pins 2-3 Disabled
GbE LAN Ports Enable/Disable
Jumpers JPL1 and JPL2 are used to
enable or disable LAN ports 1 and 2,
respectively. See the table on the right
for jumper settings.
GbE LAN Enable
Jumper Settings

Pins 1-2 Enabled (Default)
Pins 2-3 Disabled
SAS Port Enable/Disable
Use JPS1 to enable the onboard SAS
ports. See the table on the right for
jumper settings.
SAS Port Enable/Disable
Jumper Settings

1-2 Enabled
2-3 Disabled
