SUPERSERVER 5018D-MHR7N4P User's Manual
10G LAN Activity LED
The 10G LAN Activity LED for LAN7 is
located at LEDT2, and the 10G LAN LED
Activity LED for LAN8 is located at LEDT4.
When the LEDs are blinking, LAN7/LAN8
are active. See the table on the right for

10G LAN Activity
LED Indicator

LEDT2
Green: Blinking
LAN7 Active
LEDT4
Green: Blinking
LAN8 Active
Unit Identication LED
A rear UID LED indicator (LED7) is located
       
the I/O back panel. The front panel UID
LED is located at pin 7 of the Front Control
Panel at JF1. Connect a cable to pin 7 on
JF1 for front panel UID LED indication.
When you press the UID switch, both rear
UID LED and front panel UID LED Indica-
tors will be turned on. Press the UID switch
again to turn off both LED Indicators. These
    
of a system unit that may be in need of
service.
Note: UID can also be triggered via IPMI
on the motherboard. For more information
on IPMI, please refer to the IPMI User's
Guide posted on our website at http://www.
supermicro.com.
UID LED
Status
Color/State Status
Blue: On 
Link Speed LED
Activity LED
