6-6
SUPERSERVER 5018D-MHR7N4P User's Manual
DVD-ROM Drive Installation (Optional)
The top cover of the chassis must be opened to gain full access to the DVD-ROM
drive bay. The 5018D-MHR7N4P accommodates only slim DVD-ROM drives. Side
mounting brackets (p/n MCP-220-81502-0N) are needed to mount a slim DVD-
ROM drive into the server. You must power down the system before installing or
removing a DVD-ROM drive.
Removing the Chassis Cover
1. While in a rack, grasp the two handles on either side and pull the unit straight
out until it locks (you will hear a "click").
2. Depress the two buttons on the top of the chassis to release the top cover
and at the same time, push the cover away from you until it stops. You can
then lift the top cover from the chassis to gain full access to the inside of the
server.
Removing/Installing a Drive
1. Power down the system and unplug the power cord from the rear of the
power supply. Open the chassis cover
2. Secure the left rail (A) to the left side of the DVD drive using two screws (B).
3. Attach the right rail (C) to the right side of the DVD drive using two screws
(D).
4. Carefully slide the DVD drive and into the chassis.
5. Plug the power cord into the power supply and power up the system.
