Connector Description
AUDIO FP Front Panel Audio Header
BT1 Onboard Battery
COM1 COM1 Port Header
CPU_FAN1 CPU Fan Header
DVI Digital Video Interface Port
HD AUDIO Back Panel HD Audio Ports
HDMI/DP High Denition Multimedia Interface/DisplayPort
I-SATA0~5 Intel® PCH Serial ATA (SATA) 3.0 Ports 0~5 (6Gb/sec)
JD1 Pin 1~4: External Speaker
JF1 Front Control Panel Header
JL1 Chassis Intrusion Header
JPW1 24-pin ATX Power Connector (Required)
JPW2 8-pin CPU Power Connector (Required)
JSD1 SATA DOM (Disk On Module) Power Connector
JSPDIF_OUT Sony/Philips Digital Interface (S/PDIF) Out Header
JSTBY1 Standby Power Header
JTPM1 Trusted Platform Module (TPM) Header
KB/MOUSE Keyboard/Mouse
LAN RJ45 Gigabit Ethernet Port
PCIE M.2 CONNECTOR 1 PCI-E M.2 Connector 1, small form factor devices and other portable
devices for High speed NVMe SSDs
SYS_FAN1/SYS_FAN2 System Fan Headers
USB 0/1 Back Panel USB 2.0 Ports
USB 2/3 Front Panel Accessible USB 2.0 Header
USB 4/5, USB 6/7 Back Panel USB 3.0 Ports
USB 8/9 Front Panel Accessible USB 3.0 Header
LED Description Color/State Status
LED1
Power On
S3 (Suspend to RAM) LED
Power On: Green On
S3: Green Blinking
See page 2-31
