Chapter 4: AMI BIOS
4-31
Onboard LAN1 Option ROM
Select PXE (Preboot Execution Environment) to boot the computer
using a PXE device installed in a LAN port specied. Select Disabled
to prevent system boot using a device installed in a LAN port. The
options are Disabled and PXE.
Network Stack
Select Enabled to enable PXE (Preboot Execution Environment) or UEFI
(Unied Extensible Firmware Interface) for network stack support. The
options are Enabled and Disabled. If this feature is enabled, the two
features below are available.
Ipv4 PXE Support
Select Enabled to enable Ipv4 PXE (Preboot Execution Environ-
ment) for boot support. If this feature is set to Disabled, Ipv4
PXE boot option will not be supported. The options are Enabled
and Disabled.
Ipv6 PXE Support
Select Enabled to enable Ipv6 PXE (Preboot Execution Environ-
ment) for boot support. If this feature is set to Disabled, Ipv6
PXE boot option will not be supported. The options are Enabled
and Disabled.
