Supero X10SLQ - Headers and Connectors List

Chapter 1: Introduction
1-5
X10SLQ/X10SLQ-L Headers/Connectors
Connector Description
Audio FP Front Panel Audio Header
HD AUDIO High-Denition Audio Connectors (on the I/O back panel)
Battery Onboard Battery
COM1-COM4 COM1/COM2/COM3/COM4 Port Headers
Fan1-Fan4 System/CPU Fan Headers (Fan1: CPU Fan)
HDMI/DP Backpanel HDMI/DisplayPort
JD1 Speaker/buzzer (Pins 3-4: Buzzer, Pins 1-4: External Speaker)
JF1 Front Panel Control Header
JL1 Chassis Intrusion Header
JLED1 Power LED Indicator Header
JP3 WPAN LED Header (from mini PCI-E card)
JP4 WLAN LED Header (from mini PCI-E card)
JP5 WWAN LED Header (from mini PCI-E card)
JPW1 24-pin ATX Main Power Connector (Required)
JPW2 +12V 4-pin CPU power Connector (Required)
JSD1 SATA DOM (Device_On_Module) Power Connector
JTPM1 Trusted Platform Module/Port 80 Connector
JWOR1 Wake_On-Ring Header
KB/Mouse Keyboard/Mouse Connectors (Not available on the -L model)
LAN1/LAN2 Gigabit (RJ45) Ports (LAN1/2)
SP1 Internal Speaker/Buzzer
I-SATA0-4 (Intel-)Serial ATA (SATA 3.0) Ports 0-4 (6Gb/sec) from the Q87
mini-PCIe slot Mini-PCIe Slot with mSATA (Version 3.1) and 3G SIM card socket for
WWAN card (Not available on the -L model)
Slot 5 PCI-Express 2.0 x1 Slot
Slot 7 PCI-Express 3.0 x16 Slot
Slot 4 PCI-Express 2.0 x4 Slot
T-SGPIO 1/2 Serial_Link General Purpose I/O Connection Headers 1/2
USB 0/1, 4/5 Backpanel USB 2.0 Ports 0/1, 4/5 (USB 0/1: Not available on the
-L model)
USB 2/3, 10/11 Front Panel USB 3.0 Ports 2/3, 10/11 (USB 10/11: Not available on
the -L model)
USB 6/7, USB 8/9 Front Panel Accessible USB 2.0 Headers 6/7, 8/9
VGA/DVI-D Backpanel VGA/DVI-D (Digital Video Interface) Port
