Chapter 1: Overview
1-7
Motherboard Features
CPU
• Dual Intel
®
E5-2600 (V2) Series (Socket R) proces-
sors; each processor supports two full-width Intel
QuickPath Interconnect (QPI) links (with support of
up to 8.0 GT/s per QPI link)
Note: For the E5-2600 V2 CPU to work properly,
please update your BIOS to BIOS R3.0.
CPU TDP
• Thermal Design Power (TDP) up to 150 Watts*
Memory
• Integrated memory controller supports up to
1TB of 240-pin Registered (RDIMM)/Load Re-
duced (LRDIMM)/Non-Volatile (NVDIMM) ECC
or Unbuffered (UDIMM) ECC/Non-ECC DDR3
1866/1600/1333/1066/800 MHz memory in 16 slots
(1866 MHz is not available on NVDIMMs.)
Note 1: For the latest memory updates, please
refer to our website at http://www.supermicro.
com/products/motherboard.
Note 2: NVDIMM memory support is avail-
able on the X9DRH-iF & X9DRH-iF-NV only.
Please contact your Supermicro sales repre-
sentatives for the most current list of supported
NVDIMM modules. 1866MHz is not supported
by NVDIMM.
Chipset
• Intel® C602 (PCH)
Expansion
• Three (3) PCI-E x8 slots (CPU1 Slots 1, 2, 3)
• Three (3) PCI-E x8 slots (CPU 2 Slots 5, 6, 7)
• One (1) PCI-E 3.0 x16 (CPU 2 Slot 4)
Slots
Graphics
• Nuvoton BMC Video Controller (Matrix E200)
Network
• One Intel I350/X540 10-Gigabit Ethernet Dual-Channel
Controller for LAN1/LAN2 ports (GLAN Ports for -7F/-
iF/-iF-NV; 10GLAN Ports for -7TF/-iTF)
• Nuvoton WPCM 450 Baseboard Controller (BMC)
supports IPMI_LAN 2.0
