Chapter 1: Overview
1-3
Motherboard Layout
Note 1: X9DRL-3F, built upon the PCH C606 chip, supports two (2) SATA
3.0, four (4) SATA 2.0, and eight (8) SAS/SATA2 connections. X9DRL-iF,
based on the PCH C602 chip, supports eight SATA 2.0 and two SATA 3.0
connections.
Note 2: For the latest CPU/Memory updates, please refer to our website
at http://www.supermicro.com/products/motherboard/ for details.
Note 3: Changing BMC log-in information is recommended during initial
system power-on. The default username is ADMIN and password is
ADMIN. For BMC best practices, please refer to: http://www.supermicro.
com/products/nfo/les/IPMI/Best_Practices_BMC_Security.pdf
