Motherboard Features
CPU
• Dual Intel
®
E5-2600(v2) Series Processors (Socket
R LGA 2011); each processor supports two full-width
Intel QuickPath Interconnect (QPI) links (16.0 GT/s
one direction per QPI) up to 95W.
Note: For Intel E5-2600(v2) processor support,
BIOS version 3.0 or above is required.
Memory
• Integrated memory controller supports up to 512 GB
of Load Reduced (LRDIMM), 256 GB of Registered
(RDIMM) or 64 GB of Unbuffered (UDIMM) ECC/Non-
ECC DDR3 800/1066/1333/1600/1866 MHz 240-pin
4-channel memory modules in eight DIMM slots.
Note 1: 1866 MHz memory speed is dependent
on Intel E5-2600v2 CPUs.
Note 2: For the latest memory updates, please
refer to the Tested Memory List posted on our
website (http://www.supermicro.com/products/
motherboard).
• Virtualization: VT-x, VT-d, and VT-c
Chipset
• Intel® PCH C606/C602
Expansion
• Three (3) PCI Express 3.0 x8 slots (CPU1 Slot4/
Slot5/Slot6)
• One (1) PCI-Express 2.0 x4 in x8 slot (PCH Slot3),
• One (1) PCI-Express 2.0 x1 slot (PCH Slot1),
• PCI 33 MHz slot (Slot2)
Slots
Graphics
• Nuvoton BMC Video Controller (Matrox G200eW)
Network
• Dual Intel 82574 Gigabit (10/100/1000 Mb/s) Ethernet
Controllers for LAN 1/LAN 2 ports.
• Nuvoton WPCM450 Base-board Controller (BMC)
supports IPMI_LAN 2.0
I/O Devices
SATA/SAS Connections (X9DRL-3F Only)
• SATA Ports Two (2) SATA 3.0 Ports
and Four (4) SATA 2.0
Ports
• RAID (Windows/Linux) RAID 0, 1, 5, 10
• SAS Ports Eight (8) SAS/SATA 2.0
Ports (SAS 0~3, 4~7)
• RAID (Linux) RAID 0, 1, 10
