X9DRL-3F/X9DRL-iF Motherboard User’s Manual
Warning: To avoid damaging the power supply or the motherboard, be sure to use
a power supply that contains a 24-pin and two 8-pin power connectors. Be sure to
connect the power supply to the 24-pin power connector (JPW4), and two 8-pin power
connectors (JPW1, JPW2) on the motherboard. Failure in doing so will void the manu-
facturer warranty on your power supply and motherboard.
(PCH) Slot1 PCI-Express 2.0x1 Slot
Slot2 PCI 33 MHz Slot
(PCH) Slot3 PCI-Express 2.0 x4 in x8 Slot
(CPU1)Slot4/Slot5/Slot 6 PCI-Express 3.0 x8 Slots
(S-)SGPIO1/2 Serial (SAS) General Purpose I/O Headers 1/2
(T-)SGPIO1/2 Serial (SATA) General Purpose I/O Headers 1/2
(FP) USB 0/1, 2/3 Front Panel USB Connections 0/1, 2/3
(FP) USB 4 FP-Accessible Type A USB Connections 4
(BP) USB 6/7, 8/9 Backpanel USB Connections 6/7, 8/9
VGA Backpanel VGA Port
X9DRL-3F/X9DRL-iF LED Indicators
LED Description State Status
LED1 Rear UID LED Blue: On Unit Identied
PWR LED PWR LED Green: On PWR On
LEDM1 BMC Heartbeat LED Green BMC Normal
