Indicators
A Unit Identifier (JUIDB) switch, a
backplane LED indicator and a Front
Panel UID header are located on the
motherboard. The UID switch is located
next to the VGA port on the backplane.
The Rear UID LED indicator (LED1)
is located next to the UID switch. The
Front Panel UID LED header is located
at Pins 7/8 of the Front Control Panel
at JF1. Connect a cable to Pin 8 on
JF1 for Front Panel UID LED connec-
tion. When you press the UID switch,
both Rear UID LED and Front Panel
UID LED will be turned on. Press the
UID switch again to turn off both LEDs.
These UID Indicators provide easy
identication of a system unit that may
be in need of service.
Note: UID can also be trig-
gered via IPMI on the mother-
board. For more information
on IPMI, please refer to the
IPMI User's Guide posted on
our website @ http://www.
supermicro.com.
UID Switch
Pin# Denition
1 Ground
2 Ground
3 Ground
4 Button In
1. UID Switch
2. Rear UID LED (LED3)
3. Front UID LED Header
UID LED (LED3)
Status
Color/State OS Status
Blue: On Windows OS Unit Identied
Blue:
Blinking
Linux OS Unit Identied
3
1
2
1
