Supero X9DRL-iF User Manual

Chapter 1: Overview
1-5
X9DRL-3F/X9DRL-iF Jumpers
Jumper
Description Default Setting
JBT1
Clear CMOS See Chapter 2
JI
2
C1/JI
2
C2
SMB to PCI-E Slots Off (Disabled)
JPB1 BMC Enabled Pins 1-2 (Enabled)
JPG1 VGA Enabled Pins 1-2 (Enabled)
JPL1/JPL2 GLAN1/GLAN2 Enable Pins 1-2 (Enabled)
JPME1 Management Enigne (ME) Recovery
Mode Enable
Pins 1-2 (Normal)
JPME2 Management Engine (ME)
Manufacture Mode
Pins 1-2 (Normal)
JWD1 Watch Dog Timer Enable Pins 1-2 (Reset)
X9DRL-3F/X9DRL-iF Connectors
Connectors Description
Battery Onboard CMOS Battery (See Chpt. 3 for Used Battery
Disposal)
Buzzer Onboard Buzzer (Internal Speaker)
COM1/COM2 Backplane COM Port1/Front Accessible COM2 Header
Fan1~6, FanA, FanB CPU/System Fan Headers
JD1 Speaker/Power LED Indicator
JF1 Front Panel Control Header
JIPMB1 4-pin External BMC I
2
C Header (for an IPMI Card)
JL1 Chassis Intrusion
JOH1 Overheat LED Indicator
JPI
2
C1 Power Supply SMBbus I
2
C Header
JPW1/2 12V 8-Pin Power Connectors (See Warning on Pg. 1-6.)
JPW4 24-Pin ATX Main Power Connector (See Warning on Pg.
1-6.)
JSD1 SATA DOM (Device on Module) Power Connector
JSTBY1 +5V Standby Power Header
JTPM1 TPM (Trusted Platform Module)/Port 80
JUIDB UID (Unit Identication) Switch
LAN1/LAN2 G-bit Ethernet Ports 1/2
(IPMI) LAN IPMI_Dedicated LAN
(I-)SATA0~5 Intel PCH SATA Connectors (0~5)
(S-)SATA/SAS0~3 SATA/SAS Connectors (0~3)
(S-)SAS4~7 SAS Connections 4~7 (for X9DRL-3F only)
