X9DRL-3F/X9DRL-iF Motherboard User’s Manual
Memory Support for the X9DRL-3F/X9DRL-iF Motherboard
The X9DRL-3F/X9DRL-iF motherboard supports up to 512 GB of Load Reduced
(LRDIMM), 256 GB of Registered (RDIMM) or 64 GB of Unbuffered (UDIMM)
ECC/Non-ECC DDR3 800/1066/1333/1600/1866 MHz 240-pin 4-channel memory
modules in eight DIMM slots.
Note: For the latest memory updates, please refer to the Tested Memory
List posted on our website (http://www.supermicro.com/products/mother-
board).
Processor & Memory Module Population Conguration
For memory to work properly, follow the tables below for memory installation.
Processors and their Corresponding
Memory Modules
CPU# Corresponding DIMM Modules
CPU1 P1-
DIMMA1
P1-
DIMMB1
P1-
DIMMC1
P1-
DIMMD1
CPU2 P2-
DIMME1
P2-
DIMMF1
P2-
DIMMG1
P2-
DIMMH1
Processor and Memory Module Population
Number of
CPUs+DIMMs
CPUandMemoryPopulationCongurationTable
(*For memory to work proper, please install DIMMs in pairs)
1 CPU &
2 DIMMs
CPU1
P1-DIMMA1/P1-DIMMB1
1 CPU &
4 DIMMs
CPU1
P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1
2 CPUs &
2 DIMMs
CPU1 + CPU2
P1-DIMMA1, P2-DIMME1
2 CPUs &
4 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1
2 CPUs &
6 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1, P2-DIMME1/P2-DIMMF1/P2-DIMMG1
2 CPUs &
8 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-
DIMMG1/P2-DIMMH1
Notes: 1866 MHz memory speed is dependent on Intel E5-2600v2
CPUs. For Intel E5-2600(v2) processor support, BIOS version 3.0 or
above is required.
