Bottom and Back Side
Bottom
Back
Star-shaped screw hole for fixing a body to a metal bracket
3 pin connector – wiegand input or wiegand output
5 pin connector – power and RS485
4 pin connector – ethernet (TCP/IP)
7 pin connector – digital input and relay output
DIP switch : RS485 termination setting
(Refer to “RS485 Connection” pages for details)
Network default setting
(Refer to “Network Default Setting” pages for details)
