Electrical Specification
Min. Typ. Max. Notes
Power
Voltage (V) 10.8 12 13.2 Use regulated DC power adaptor only
Current (mA) - 250
Switch Input
V
IH
(V) 2.0 - 10.0
V
IL
(V) - - 0.4
Pull-up resistance (Ω) - 4.7k - The input ports are pulled up with 4.7k resistors
TTL/Wiegand Output
V
OH
(V) - 5 -
V
OL
(V) - 0.8 -
Pull-up resistance (Ω) - 4.7k -
The outputs ports are open drain type, pulled up with 4.7k resistors
internally
Relay
Switching capacity (A) - -
1
0.3
30V DC
125V AC
Switching power
(resistive)
- -
30W
37.5VA
DC
AC
Switching voltage (V) - -
110
125
DC
AC
