29
ⒸCopyright 2007 Suprema Inc.
Installation Reference 3 – Network
Door Zone 2 (Anti passback)
Door Zone 1 (Anti passback)
BioStation BioEntry Plus BioEntry Plus Secure I/O
RS485 RS485
LAN
BioStation Secure I/O BioEntry Plus
Exit Button
PC Server
PC Client
PC Client
RS485
Enroll Scanner
