Specifications
Item Specification
CPU 400MHz DSP
Fingerprint sensor 500dpi Optical / Capacitive sensor
User capacity 5000 users (10,000 templates)
Log capacity 50,000 events
Matching speed Less than 1 second
Operation mode Fingerprint, RF Card, RF card + Fingerprint
Network Interface TCP/IP, RS485
Internal relay Deadbolt, EM lock, door strike, automatic door
TTL I/O 2 inputs for exit switch and door sensor
Wiegand In/Out 1 Port (Wiegand Input or Wiegand Output is used according to the configuration.)
Sound and Interface Multi-color LED and multi-tone buzzer
Rated Voltage
DC 12V (Min. 500mA and above)
(When sharing the power with a device such as electric door lock, enough power is
required considering the power requirement for the connected device.)
Card option
125kHz EM card (EM4100)
125kHz HID Proximity Card
13.56MHz Mifare Card
Size 50 x 160 x 37 mm (Width x Height x Depth)
Certified KCC, CE, FCC
