Relay Connection - Automatic door
BioEntry Plus
Automatic
Door
(7) Normally Open / N.O. (White)
(6) Common (Blue)
(5) Normally Closed / N.C. (Orange)
Door
Controller
RTE Switch
Presence
Detector
