Kitting Information
Flare 5-Band Kit with Omni (US): SC-Poly-DT-O-Kit
Flare 5-Band Kit with Yagi (Canada): SC-Poly-DT-CA
Component Product number Gain/Loss Note
LTE-A
707 MHz
LTE-V
731 MHz
Cellular
800 MHz
PCS
1900 MHz
AWS
1700 / 2100 MHz
Outdoor Antenna* SC-289W 3 dBi 3 dBi 3 dBi 4 dBi 4 dBi / 4 dBi
SC-231W 10 dBi 10 dBi 10 dBi 10 dBi 10 dBi / 10 dBi
Outdoor Cable* SC-RG6-50 3.32 dB 3.32 dB 3.75 dB 6.42 dB 6.22 dB / 6.68 dB 50 Feet or longer
Indoor Antenna SC-322W 2.5 dBi 2.5 dBi 3 dBi 5 dBi 4 dBi / 5 dBi
SC-302W 2.5 dBi 2.5 dBi 3 dBi 5 dBi 4 dBi / 5 dBi
* The Flare booster is suitable for use with all equivalent and lower gain antennas, as well as, equivalent or greater lengths of cable.
Frequency (MHz) Bandwidth (MHz) Input (dBm) Mean Power (dBm) Gain (dB)
Uplink: 1710-1755 75.0 -49.4 24.3 73.7
Uplink: 1850-1915 75.3 -49.8 21.7 71.5
Uplink: 824-849 36.3 -43.6 20.6 64.2
Uplink: 698-716 23.8 -40.1* 23.2 63.3
Uplink: 777-787 24.0 -45.9* 18.3 64.2
Downlink: 2110-2155 86.5 -54.7* 20.4 75.1
Downlink: 1930-1995 74.4 -52.3* 22.0 74.3
Downlink: 869-894 36.3 -36.7 20.8 57.5
Downlink: 728-746 33.8 -37.7 19.4 57.2
Downlink: 746-756 33.9 -32.8 19.8 52.6
*Mean power: Measurements obtained on section 6.2 where Pmean = P01+3dB
Flare Dual Band Kit with Yagi (Canada): SC-Dual-DT-Y-CA-Kit
Component Product number Gain/Loss Note
Cellular - 800 MHz PCS - 1900 MHz
Outdoor Antenna* SC-289W 3 dBi 4 dBi
SC-231W 10 dBi 10 dBi
Outdoor Cable* SC-RG6-50 3.75 dB 6.42 dB 50 Feet or longer
Indoor Antenna SC-322W 3 dBi 5 dBi
SC-302W 3 dBi 5 dBi
* The Flare booster is suitable for use with all equivalent and lower gain antennas, as well as, equivalent or greater lengths of cable.
