ENGINE CONTROL SYSTEM 3-45
OIL CHANGE REMINDER SYSTEM
This system informs the operator of the time for replacing
ENGINE OIL on the basis of the recommended maintenance
schedule. When the total motor operating hours have reached
the preprogrammed hours, the “OIL” lamp will flash, and the
buzzer will begin a series of double beeps if engine is not run-
ning (but ignition switch is ON). The above mentioned indication
will repeat until the activated system is manually cancelled.
NOTE:
This system will activate up to 2 100 hour’s operation.
INDICATION OF SYSTEM ACTIVATION
CANCELLATION
Procedure
1. Turn the ignition key to “ON” position.
2. Pull out the emergency stop switch plate

1.
3. Pull up the emergency stop switch knob

2 three times in ten
seconds. A short beep will be heard if cancellation is suc-
cessfully finished.
4. Turn the ignition key to “OFF” position.
5. Set the switch plate

1 in original position.
NOTE:
• Canceling of the system activation is possible regardless of whether or not the engine oil has been
replaced. Once the system has operated, however, SUZUKI strongly recommends that the engine oil be
replaced before canceling the system activation.
• Even if the engine oil has been replaced with the system not operating, it is still necessary to perform the
cancellation.
Action
Starting operation
CancellationIndication
(*1) (*4)
CancellationIndication
CancellationIndication
CancellationIndication
Repeat
(*2) (*4)
(*3) (*4)
(*3) (*4)
*1 : Lapse of initial 20 hour’s operation
*2 : Lapse of 80 hour’s operation
*3 : Lapse of 100 hour’s operation
*4 : When performing cancellation before
system activation
Buzzer OIL lamp
Ign. switch
Buzzer
Oil Lamp
ON
OFF
ON
OFF
OFF ON
: Indicator check (No relation to OIL CHANGE REMINDER SYSTEM)
