2-6 PERIODIC MAINTENANCE
GEAR OIL
1. Place outboard motor upright on a level surface.
2. Place a container under the lower unit.
3. Remove lower gear oil drain plug first, then remove gear oil
level plug and drain gear oil.
4. Fill with recommended gear oil through oil drain hole until oil
just starts to flow out from oil level hole.
Gear oil amount: 1 100 ml (37.2/38.7 US/Imp. oz)
Recommended oil:
SUZUKI OUTBOARD MOTOR GEAR OIL or
SAE #90 HYPOID GEAR OIL
5. Install oil level plug before removing oil filler tube from drain
hole.
6. Install oil drain plug.
#
NOTE:
To avoid a possible low gear oil level, recheck gear oil level 10
minutes after doing procedure in step 6. If oil level is low, add
additional gear oil until level is correct.
Change initially after 20 hours (1 month) and every
100 hours (6 months).
1 Oil level plug
2 Oil drain plug
Do not re-use gaskets once removed. Always use a
new gasket.
