GENERAL INFORMATION 1-11
*
These specifications are subject to change without notice.
For DF200T/225T/250T specification, see page 1-9.
DIMENSIONS & WEIGHT
PERFORMANCE
POWER HEAD
Item Unit
Data
DF200Z DF225Z DF250Z
PRE-FIX 20001Z 22501Z 25001Z
Overall length
(front to back)
mm (in.) 897 (35.3)
Overall width
(side to side)
mm (in.) 572 (22.5)
Overall height UL mm (in.) 1 834 (72.2)
XX mm (in.) 1 961 (77.2)
Weight
(without engine oil)
UL kg (lbs) 263 (580)
XX kg (lbs) 268 (591)
Transom height UL mm (in. type) 632 (25)
XX mm (in. type) 759 (30)
Maximum output kW (PS) 147 (200) 165 (225) 184 (250)
Recommended operating range r/min 5 000 – 6 000 5 000 – 6 000 5 500 – 6 100
Idle speed r/min 650 ± 50 (in-gear: Approx. 650)
Engine type 4-stroke DOHC
Number of cylinders V-6
Bore mm (in.) 95 (3.74)
Stroke mm (in.) 85 (3.35)
Total displacement cm
3
(cu. in) 3 614 (220.5)
Compression ratio : 1 9.5
Spark plug NGK BKR6E
Ignition system Full-transistorized ignition
Fuel supply system Multi-point sequential electronic fuel injection
Exhaust system Through prop exhaust
Cooling system Water cooled
Lubrication system Wet sump by trochoid pump
Starting system Electric
Throttle control Remote control
16
