Suzuki DF200 - ELECTRICAL, DIAGNOSTICS, AND SERVICE TOOLS

1-18 GENERAL INFORMATION
ELECTRICAL
STARTER MOTOR
Item Unit
Data
DF200T/Z DF225T/Z DF250T/Z
Ignition timing Degrees
at r/min
BTDC 0 – 26 ± 3 BTDC 0 – 25 ± 3 BTDC 0 – 26 ± 3
Over revolution limiter r/min 6 200 6 300
CKP sensor resistance
Ω
at 20° 168 – 252
CMP sensor resistance
Ω
at 20° —
Ignition coil resistance Primary
Ω
at 20° —
Secondary k
Ω
at 20° —
Battery charge coil resistance
Ω
at 20° 0.32 – 0.48
Battery charge coil output (12V) Watt 648
Standard spark plug Type NGK BKR6E
Gap mm (in.) 0.7 – 0.8 (0.028 – 0.031)
Fuse amp. rating
A
Main fuse: 60
Sub fuse: 30
Recommended battery capacity
(12V)
Ah (kC) 100 (360) or larger
Fuel injector resistance
Ω
at 20 °C 10 – 14
IAC valve resistance
Ω
at 20 °C 25 – 34
IAT sensor/Cylinder temp. sensor/
Ex. mani. temp. sensor (Thermistor
characteristic)
k
Ω
at 25 °C 1.8 – 2.3
ECM main relay resistance
Ω
at 20 °C 145 – 190
Starter relay coil resistance
Ω
at 20 °C 145 – 190
PTT motor relay coil resistance
Ω
at 20 °C 25 – 37
Max. continuous time of use Sec. 30
Motor output kW 1.4
Brush length STD mm (in.) 16.0 (0.63)
Limit mm (in.) 12.0 (0.47)
Commutator undercut STD mm (in.) 0.5 – 0.8 (0.02 – 0.03)
Limit mm (in.) 0.2 (0.01)
Commutator outside diame-
ter
STD mm (in.) 29.0 (1.14)
Limit mm (in.) 28.0 (1.10)
Commutator outside diame-
ter difference
STD mm (in.) 0.05 (0.002)
Limit mm (in.) 0.40 (0.016)
