1A-76 Engine General Information and Diagnosis:
Step Action Yes No
1 1) Lift and support the fuel tank. Refer to “Fuel Tank
Removal and Installation” in Section 1G (Page 1G-9).
2) Remove the air cleaner box cover. Refer to “Air Cleaner
Element Removal and Installation” in Section 1D
(Page 1D-6).
3) Check the STVA lead wire coupler (1) for loose or poor
contacts.
4) Check whether the STVs open by turning the ignition
switch ON.
Is the operation OK?
Go to Step 2. • Loose or poor
contacts on the STVA
coupler.
• Open or short circuit
in the B/Lg, P/W, G or
W/B wire.
• If wire and
connection are OK,
go to Step 2.
1
I947H1110040-01
I947H1110127-01
