Steering / Handlebar: 6B-12
Specifications
Tightening Torque Specifications
B838H26207001
NOTE
The specified tightening torque is also described in the following.
“Handlebar Components (Page 6B-1)”
“Steering Components (Page 6B-5)”
“Steering Damper Construction (Page 6B-6)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-9)”.
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Front fork upper clamp bolt 23 2.3 16.5 )(Page 6B-3)
Handlebar clamp bolt 23 2.3 16.5 )(Page 6B-3)
Steering stem head nut
90 9.0 65.0
)(Page 6B-3) /
)(Page 6B-9)
Steering stem nut 45 N⋅m (4.5 kgf-m, 32.5 lb-ft) then turn back
1/2 – 1/4
)(Page 6B-8)
Steering stem lock-nut 90 9.0 65.0 )(Page 6B-8)
Steering damper bolt 23 2.3 16.5 )(Page 6B-9)
Steering damper nut 23 2.3 16.5 )(Page 6B-9)

Suzuki GSX-R750 Specifications

General

Engine Type	4-stroke, 4-cylinder, liquid-cooled, DOHC
Displacement	750cc
Compression Ratio	12.5:1
Fuel System	Fuel injection
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Overall Width	710 mm (28.0 in)
Ground Clearance	130 mm (5.1 in)
Seat Height	810 mm (31.9 in)
Curb Weight	190 kg (419 lbs)
Ignition	Electronic ignition (transistorized)
Starter	Electric
Final Drive	Chain
Bore x Stroke	70.0 mm x 48.7 mm
Transmission	6-speed, constant mesh
Rear Brakes	Disc
Front Tires	120/70ZR17M/C (58W)
Rear Tires	180/55ZR17M/C (73W)
Fuel Tank Capacity	17.0 L (4.5 US gallons)
Overall Length	2, 030 mm (79.9 in)
Wheelbase	1390 mm (54.7 in)
Front Brakes	Dual hydraulic disc
