1D-76 Engine Mechanical:

Specifications

Service Data

B817H21407001

Valve + Guide

Unit: mm (in)

Camshaft + Cylinder Head

Unit: mm (in)

Item Standard Limit

Valve diam.

IN. 23 (0.91) —

EX. 20 (0.79) —

Valve clearance (when cold)

IN. 0.10 – 0.20 (0.004 – 0.008) —

EX. 0.20 – 0.30 (0.008 – 0.012) —

Valve guide to valve stem clearance

IN. 0.010 – 0.037 (0.0004 – 0.0015) —

EX. 0.030 – 0.057 (0.0012 – 0.0022) —

Valve stem deflection IN. & EX. — 0.35 (0.014)

Valve guide I.D. IN. & EX. 4.500 – 4.512 (0.1772 – 0.1776) —

Valve stem O.D.

IN. 4.475 – 4.490 (0.1762 – 0.1768) —

EX. 4.455 – 4.470 (0.1754 – 0.1760) —

Valve stem runout IN. & EX. — 0.05 (0.002)

Valve head thickness IN. & EX. — 0.5 (0.02)

Valve seat width IN. & EX. 0.9 – 1.1 (0.035 – 0.043) —

Valve head radial runout IN. & EX. — 0.03 (0.001)

Valve spring free length IN. & EX. — 40.4 (1.59)

Valve spring tension IN. & EX.

182 – 210 N (18.2 – 21.0 kgf, 40.1 – 46.3 lbs)

at length 36.0 mm (1.42 in)

—

Item Standard Limit

Cam height

IN. 35.65 – 35.69 (1.4035 – 1.4051) 35.35 (1.3917)

EX. 35.37 – 35.41 (1.3925 – 1.3941) 35.07 (1.3807)

Camshaft journal oil clearance IN. & EX. 0.032 – 0.066 (0.0013 – 0.0026) 0.150 (0.0059)

Camshaft journal holder I.D. IN. & EX. 24.012 – 24.025 (0.9454 – 0.9459) —

Camshaft journal O.D. IN. & EX. 23.959 – 23.980 (0.9433 – 0.9441) —

Camshaft runout IN. & EX. — 0.10 (0.004)

Cam chain pin (at arrow “3”) 16th pin —

Cylinder head distortion — 0.20 (0.008)
