Wheels and Tires: 2D-26
Specifications
Service Data
B817H22407001
Wheel
Unit: mm (in.)
Tire
Tightening Torque Specifications
B817H22407002
NOTE
The specified tightening torque is also described in the following.
“Front Wheel Components (GSF650/S/U/SUK7) (Page 2D-2)”
“Front Wheel Assembly Construction (GSF650/S/U/SUK7) (Page 2D-3)”
“Rear Wheel Components (GSF650/S/U/SUK7) (Page 2D-9)”
“Rear Wheel Assembly Construction (GSF650/S/U/SUK7) (Page 2D-10)”
“Front Wheel Components (GSF650A/UA/SA/ASUK7) (Page 2D-18)”
“Front Wheel Assembly Construction (GSF650A/UA/SA/ASUK7) (Page 2D-19)”
“Rear Wheel Components (GSF650A/UA/SA/ASUK7) (Page 2D-23)”
“Rear Wheel Assembly Construction (GSF650A/UA/SA/ASUK7) (Page 2D-24)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-7)”.
Item Standard Limit
Wheel rim runout
Axial 2.0 (0.08)
Radial 2.0 (0.08)
Wheel axle runout
Front 0.25 (0.010)
Rear 0.25 (0.010)
Wheel rim size
Front 17 M/C x MT3.50
Rear 17 M/C x MT5.00
Item Standard Limit
Cold inflation tire pressure
(Solo riding)
Front 250 kPa (2.50 kgf/cm
2
, 36 psi)
Rear 250 kPa (2.50 kgf/cm
2
, 36 psi)
Cold inflation tire pressure
(Dual riding)
Front 250 kPa (2.50 kgf/cm
2
, 36 psi)
Rear 290 kPa (2.90 kgf/cm
2
, 42 psi)
Tire size
Front 120/70 ZR17M/C (58 W)
Rear 160/60 ZR17M/C (69 W)
Tire type
Front
GSF650/U BRIDGESTON BT011F G
GSF650S/SU BRIDGESTON BT011F M
Rear BRIDGESTON BT020R G
Tire tread depth
(Recommended depth)
Front 1.6 mm (0.06 in.)
Rear 2.0 mm (0.08 in.)
Fastening part
Tightening torque
Note
Nmkgf-mlbf-ft
Front brake caliper mounting bolt 23 2.3 16.5 )(Page 2D-5)
Front axle
100 10.0 72.5
)(Page 2D-5) /
)(Page 2D-22)
Front axle pinch bolt
23 2.3 16.5
)(Page 2D-5) /
)(Page 2D-22)
Rear axle nut
100 10.0 72.5
)(Page 2D-12) /
)(Page 2D-25)
Front brake caliper mounting bolt 25 2.5 18.0 )(Page 2D-21)
