9A-13 Wiring Systems:
Wiring Harness Routing Diagram (GSX650FK8)
B817H29102008
2
4
“C”
“A”
“B”
3
3
3
1
I817H2910903-02
1. EVAP purge control valve (E-33 only) “A”: Pass the EVAP purge control valve lead wire lower the clutch hose (E-33 only).
2. Wiring harness No. 1 “B”: Do not make slacked lead wire.
3. Wiring harness No. 2 C”: Left & Right are symmetry.
4. Front turn signal
