16-12 FRONT FORK AND STEERING
STEERING
REMOVAL
• Remove the front wheel. (14-3)
• Remove the brake caliper. (15-6)
• Remove the front number plate.
• Remove the handlebar holder bolts 1 and handlebars.
• Remove the brake hose guide.
• Remove the front fender.
• Loosen the steering stem head nut and upper clamp bolts.
• Remove the steering stem head 1.
• Remove the front fork.
• Remove the steering nut with the special tools.
09940-14930: Steering nut socket wrench
• Remove the steering stem 1.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Suzuki RM85 and is the answer not in the manual?

Suzuki RM85 Specifications

General IconGeneral
Engine Type2-stroke, liquid-cooled, single cylinder
Displacement84.7cc
Bore x Stroke48.0 mm x 46.8 mm
IgnitionCDI
Transmission6-speed constant mesh
Final DriveChain
Front BrakesSingle hydraulic disc
Rear BrakesSingle hydraulic disc
Compression Ratio9.5:1
Front SuspensionInverted telescopic, coil spring, oil damped
Rear SuspensionSwingarm type, coil spring, oil damped
Front Tire70/100-17
Rear Tire90/100-14
Overall Width765 mm
Overall Height1, 110 mm
Wheelbase1, 240 mm (48.8 in.)
Curb Weight73 kg (161 lbs.)
Fuel Tank Capacity5.5 L
