CLEARVU2 5
INSTALLATIONS
Camera Installation Tips
• Camera(s) should be installed between 8 and 13 feet above the area to be monitored.
• Ensure there are no obstructions in the camera’s view, to maximize viewing area.
• Ensure that the sunshade is positioned to avoid glare and position cameras away from direct sunlight.
• Decide whether the camera will be wall-mounted or if it will sit on a desk/table top.
Note: If wall mounting, use the mounting hardware included in the package.
• Each camera comes with 60 feet of wire. Please make sure you mount the cameras no more than 60 feet from the DVR (unless
you have purchased additional wiring).
• We strongly recommend using a surge protected power bar and/or an Uninterrupted Power Supply (UPS) to power
the DVR and camera system.
Mounting
1. Mount each camera in the desired location no more than 60 feet from the DVR )unless you have purchased
additional wiring). You may wall mount or desk mount these cameras.
Wall Mounted Desk Mounted
2. Adjust cameras to the desired viewing angles.
Please refer to the CV67 manual for a drilling template for your camera
