SectionV:Parts
5.0.PAR.SL-520X
91H77 – BASE CYLINDER CIRCUIT SL-520X
ITEM
PART
#
QTY DESCRIPTION
WT-
lb/ea.
WT-lb/all
1 14P23 2 Adp Hyd 08FF/08FF/08FF BHD 0.30 0.60
2 14P24 2 Adp Hyd 08FF/08FF BH 0.30 0.60
3 14P25 6 Adp Hyd 08FF/08MF 90 0.30 1.20
4 14P26 6 Adp Hyd 08MF/08MF 90 0.30 1.80
5 14P27 4 Adp Hyd 08FF/08MF 45 0.30 1.20
6 14P28 2 Adp Hyd 08MF/08MB 0.30 0.60
7 14P29 1 Hose Assy 46 08-08FF/08FF 4.00 4.00
8 14P30 1 Hose Assy 42 08-08FF/08FF 3.80 3.80
9 14P31 3 Hose Assy 24 08-08FF/08FF 2.00 6.00
10 14P32 1 Hose Assy 149 08-08FF/08FF 12.00 12.00
11 14P33 1 Hose Assy 126 08-08FF/08FF 10.00 10.00
12 14P34 4 Adp Hyd 08FF Cap 0.30 1.20
13 14P41 2 Hyd Tube, 1-1/2 x 109 3.88 7.76
14 23P04 1 Hyd Valve, 2-Way 08FB 5.20 5.20
15 90H17 2 Hose Clamp Assy, 1/2 0.17 0.34
16 90H74 1 Nylon Hose Sleeve 0.25 0.25
