7.1.3 Color Change
7.1.4 Encoder
7.1.5 Repeat Work
300 Needle bar stop position error
When replacing the needle bar, the
needle bar fails to reach the proper
position.
Manually turns the needle bar to
check the load of the needle bar, and
properly place the needle bar.
No. Error Name Error Description Handling
501 Error in repeat work setting
As in (X-axis number) × (Y-axis
number) > 99, the limit of repeat
work was passed.
Make sure that repeat work should
be set as (X-axis number) × (Y-axis
number) < 99.
No. Error Name Error Description Handling
400 Error in the main shaft encoder A
Problems in signaling occurred in
the main shaft's encoder A.
Check the connection of the encoder
cable, and turn off and then on the
main switch.
401 Error in the main shaft encoder Z
Problems in signaling occurred in
the main shaft's encoder Z.
Check the encoder's cable
connection, and turn off and again
the main switch.
No. Error Name Error Description Handling
To Next Page
