⑨ Auto Color Change
This function is to enable the automatic color change function.
– The default is “Yes”, and to turn off the automatic color change function, choose “No.”
⑩ Bottom Dead Point Stop
This function is to enable the needle bat to stop at the lowest point when the embroidery work is completed.
– The default is “No,” and select “Yes (1)” to make the needle bar stop at the lowest stop position.
⑪ Frame Setting
This is to set the types of embroidery frame.
⑫ Frame Speed Setting
This is to set the frame move speed during frame feeding, such as automatic return to origin and offset move.
– The default is “High Speed(1)”. To set the low speed, enter “Low Speed (0)”.
⑬ Frame Move Method (Trimming)
This is to shake the frame left or right to separate the thread from embroidery materials
after trimming.
– The default is X(1). To set the move direction along the Y-axis direction, select Y(2). If no direction is
selected, choose “NO(0)”.
⑭ Inching stitch
When starting embroidery, the machine starts operation at the inching speed. This function is to set the
number of stitches to be made during inching operation.
– The default is 2 stitches, and the value can be adjusted at the range from 2 to 10 stitches by the unit of 1
stitch.
⑮ Needle Move Function (Offset)
This function is to lift the needle bar by activating the jump motor when it moves to the offset position.
– The default is Yes(1), and when the function is unnecessary, select No(0).
⒃ Power On Auto Origin
This function is to automatically find the origin after the power is on.
– The default is “No”. If “Yes” is chosen, but the origin setting is wrong or the machine develops problems,
all settings shall be initialized. For setting initialization, see “2) Program setting Initialization of 3.1.3
Memory”.
