Analogue Inputs
FB-N_value U_e = 0 - 10 V, Re = 100 kΩ, I_e = 0,1mA at 10 V,
X6:7 Unwired 0 V, Input protected up to max. ±40 V
FB+10V U_out = 10 V ±3%, I_out = max. 25 mA,
X6 :6
FB-Ground Earth reference point for FB +10 V
X6:5
FB-Input+ Current input 0 - 20 mA
FB-Input- Short-circuit-proof I_k = max. 50 mA
X6:3,4
Frequency Output
FB-Out_Freq Simple frequency output of the frequency inverter, keying proportion 50%
X6:2 Open collector, U_max = 24 V, I_max = 30 mA
FB-Ground Earth reference point for frequency-output
X6:1
FB-voltage outputs are related to the frequency output of FB-Ground.
The relay outputs are originally galvanically separated.
Ambient Conditions
Permitted in interior rooms
Ambient operating temperature 5 - 40°C (41 - 104°F)
Relative humidity max. 80%
Max. altitude 2,000 m
Storage and Transport Conditions
Ambient operating temperature -30 - 70°C (-22 - 158°F)
Relative air humidity 5 - 95%
Air pressure 700 - 1,060 hPa
Keep dry!
We reserve the right to make technical modifications.
Power Supply e@syDrive 4429
The mains adaptor is designed for supplies to the e@syDrive 4426
(see operating manual of power supply e@syDrive 4429, Material no. 1.003.1905)
When using a transformer, or another power pack, the secondary voltage must be provided with
insulation double that of the mains potential. This means the converter supply voltage must be
galvanically separated from the mains.
When using a transformer the Standard EN 61558 for double insulation must be observed.
Current: max. 16 A (e@syDrive 4426), max. 10 A (e@syDrive 4425).
