P86 R_protect [ASM, BLDC, BLDCS]
Resistance value of the KTY sensor at the cut-out point, selectable only if P85-motor protection is set to
KTY.
Minimum value: 500 Ω
Maximum value: 4,000 Ω
Factory setting: 1,200 Ω
8.14 Rated Motor Data
In this section, the nominal data of the connected motor should be input, this MUST do before
adjustment the other motor parameter.
The nominal data are shown on the rating plate or the data sheet.
P90 motortype [ASM, BLDC, BLDCS]
Input of motor design.
Values: no motor - no motor defined
ASM - three-phase asynchronous motor
BLDC - brushless DC motor without sensors
BLDCS - brushless DC motor with sensors (not in series version)
Test operation
Factory setting: no motor
P91 f_mot_nom [ASM, BLDC, BLDCS]
Nominal motor frequency according to rating plate in Hertz.
Minimum value: 30 Hz
Maximum value: 4,000 Hz
Factory setting: 100 Hz
P92 V_mot_nom [ASM, BLDC, BLDCS]
Rated motor voltage according to rating plate.
Minimum value: 0 V
Maximum value: 50 V
Factory setting: 6 V
P93 I_mot_nom [ASM, BLDC, BLDCS]
Rated motor current (apparent current in one phase) according to rating plate.
Minimum value: 0.5 A
Maximum value: 10 A
Factory setting: 1.0 A
P94 cos_phi [ASM, BLDC, BLDCS]
Motor power factor cos phi according to rating plate.
Minimum value: 20%
Maximum value: 100%
Factory setting: 85%
P96 no. of poles [ASM, BLDC, BLDCS]
Number of poles in the motor. This parameter is used for speed display in rpm.
Note that the number of poles and not the number of pole pairs should be input here.
Minimum value: 2 poles
Maximum value: 8 poles
Factory setting: 2 poles
