8.7 Parameter List
This list includes all displayable and alterable parameters.
In the column "Change/Display", the following abbreviations are used:
N = not alterable
S = alterable only when motor not running
I = always alterable, even when motor running
M = display and alterability dependent on P90-motortype
* = display dependent on other parameters
Par. Indication Description Value range, Unit Factory Change/
No. in display physical value setting Display
Basic parameters
P1 N_rated Frequency set-value 30 - 4000 Hz 50 I
*P7 select operation Selection operation PC application, selection - selective S
P8 speed display Selection Speed display in Hz, in rpm - in Hz I
Display values
P10 N_rated_act Current frequency set point value 0...4000 Hz - N
P11 I_limit_act Current current limit 0.5...16 A~ - N
P13 f_out_act Actual inverter frequency 0...4000 Hz - N
P14 f_motor Actual motor frequency 0...4000 Hz - N
P15 V_motor Output voltage 0...40 V~ - N
P16 V_DC_link Intermediate circuit voltage 0...75 V- - N
P18 I_mot Real motor power 0...10 A~ - N
P19 P_real Real power 0...400 W - N
P20 motor code Motor coding and motor memory 1...32 - - N
P25 inverter Operating hours counter inverter 0...65000 h 0 N
P26 motor Operating hours counter motor 0...65000 min 0 N
P30 1st error Last error - - 0 N
P31 2nd error Penultimate error - - 0 N
P32 3rd error Third-last error - - 0 N
P33 4th error Fourth-last error - - 0 N
P34 5th error Fifth-last error - - 0 N
P36 Inverter Inverter type - - - N
P37 SW panel Firmware version of panel - - - N
P39 Serialno. Serial number of Inverter - - - N
Motor parameters /
Motor operating values
P41 f_mot_min Min. motor frequency 30...100...4000 Hz 50 S M
P42 f_mot_max Max. motor frequency f_mot_nom, 100...4000 Hz P91 S
P44 I_limit Current limitation (phase current) 0.5...16 A~ 1.5*P93 I
P46 t_rise Ramp time for run-up 0.5...400 s 5 I
P47 t_fall Ramp time for fall-down 0.5...400 s 5 I
P48 t_stop Ramp time for stop DC-brake,t_down,0.5..400 s P47 I
*P50 motor start Start option, catch circuit Off, main-on, always - always I M
P51 t_start Start time for micro step operation without ramp, 0,5...100 s without ramp I M
P52 I_start Start-up current micro step oper. BLDC 0,1...16 A~ 0.1 I M *
P53 f_start Start-up frequency micro step operation 1...30 Hz 8 S M
P54 t_off Inverter switch-off time, start-up 200...1000 µs 330 S M
P55 t_DC_brake DC brake time DC brake Off, 0.1...120 s off I M
P56 I_DC_brake DC brake current DC brake 0,1...10 A- 1 I M *
P57 I_DC_stop DC stop current (at stop) Off, 0.1...3 A- off I
P58 emerg. stop Select emergency stop at mains failure inactive, on at mains failure - inactive I
