8.0 Configuration
All inverter relevant data are accessible in the form of parameters P1 - P150.
The configuration is carried out exclusively via the PC operating software.
Basic parameters
Higher parameters, upon which further adjustments are dependent (P1 / P7 / P8) (speed values, display
adjustments, operating language, mode of operation, ...)
Display values
Pure display values which cannot be changed (P10 - P34) (voltage, current and frequency values)
Motor operating parameters
Motor specific parameters for adapting the motor to the frequency inverters (P41 - P96)
Device parameters
Inverter specific parameters which can be changed (P102 - P150) (remote control)
If a parameter cannot be changed (e.g. pure display values), the value appears into grey background. This
also applies to parameters which can be changed only when the motor is not running.
If a parameter is not used, depending on the mode or other parameters, it is faded out. It is thus not
displayed and also cannot be changed.
