X4: Connection Remote Control
Connection of digital outputs (Relays)
Connection of digital inputs, analogue inputs and frequency outputs
X5: Connection PC For Configuration
Plug e@syDrive: 9-pin socket Sub-D (1) connecting cable (material no. 1.002.2025)
