10. FINAL DRIVE MECHANISM
10-1
Mechanism Diagram ··························· 10-1
Precautions in Operation···················· 10-2
Troubleshooting·································· 10-2
Final Drive Mechanism Disassembly· 10-3
Final Drive Mechanism Inspection ·····10-4
Bearing Replacement ··························10-5
Final Drive Mechanism Reassembly ··10-8
Mechanism Diagram
Final shaft
Final gear
Counter gear
Counter shaft
Drive shaft
1.0~1.4kgf-m
Bearing (6301)
Bearing (6004)
Bearing (CSB301)
Bearing (6004)
Bearing (6301)
Bearing (6204)
