5. Fuel Injection System
5-2
EFi System Vehicle Configuration
Fuel Pump
O2 Sensor
CPS
ISC
MAP Sensor
Ignition Coil
ECU
To this chapter contents
TPS
TW Sensor
INJECTOR
Rollover Sensor
ASIV
TA Sensor
