15. BRAKE SYSTEM
15-1
Front Brake System Diagram .............. 15-1
Rear Brake System Diagram-Drum Brake
.............................................................. 15-2
Rear Brake System Diagram- Disc Brake
.............................................................. 15-3
Precautions in Operation ................... 15-4
Troubleshooting.................................. 15-5
Hydraulic Disc brake........................... 15-6
Air Bleed .............................................. 15-7
Brake Caliper....................................... 15-7
Brake Disk Inspection......................... 15-8
Brake Master Cylinder ........................ 15-8
Front Brake System Diagram
Homepage
Contents
15
4.0~4.5kgf-m
0.8~1.2kgf-m
0.5~0.6kgf-m
3.0~4.0kgf-m
