13. COOLING SYSTEM
13-1
Mechanism Diagram ··························13-1
Precautions in Operation···················13-2
Troubleshooting·································13-2
Trouble Diagnosis for Cooling System
·····························································13-3
System Test········································13-5
Radiator ··············································13-6
Water Pump········································13-8
Thermostat ·········································13-12
Mechanism Diagram
Radiator filler cap
Radiator
Reserve tank
Thermo switch (fan)
Radiator filler cap
Reserve tank
Thermo switch (fan)
Coolant inlet pipe Coolant outlet pipe By-pass pipe
Thermo unit (temp meter)
Water pump
Thermostat
Cooling fan
Cooling fan
