2. MAINTENANCE INFORMATION
2-12
Special Tools List
NAME
R/L. CRANK DISASS. TOOL
NAME
CRANK SHAFT PULLER
NAME
L. CRANK SHAFT BRG. DRIVER
NO SYM-1120000-H9A NO SYM-1130000-H9A NO SYM-9100200-H9A
(ψ30mm)
(ψ22mm)
NAME
CRANK SHAFT BRG. FIXING
SOCKET
NAME
CRANK CASE BUSH PULLER
NAME
CRANK CASE BUSH PULLER
NO SYM-9100210-H9A NO SYM-1120310 NO SYM-1120320
NAME
VALVE COTTER REMOVE &
ASSEMBLY TOOL
NAME
TAPPET ADJUSTING WRENCH
NAME
TAPPET ADJUSTER
NO SYM-1471110/20 NO SYM-9001200 NO SYM-9001209
NAME
UNIVERSAL HOLDER
NAME
CLUTCH NUT WRENCH
NAME
CLUTCH SPRING
COMPRESSOR
NO SYM-2210100 NO SYM-9020200 NO SYM-2301000
