14. Brake System
14-16
ABS components location
ABS indicator
ABS control unit
Front wheel
detective disk
Front wheel
speed sensor
Rear wheel
detective disk
Rear wheel
speed sensor
ABS / EFi system
diagnostic tool coupler
