Mechanism Illustration
Front winker
Luggage box
Start / engine stop switch
Dimmer / winker / horn
seat open / pass switch
Muffler
Reserve tank
cap
Coolant filler cap
Main switch
Fuel tank /
fuel pump
Side stand
Back mirror
Headlight
Front brake lever
Rear brake lever
Home page
Contents
Main stand
Air cleaner
Taillight /
rear winker
Engine number
