Sym MaxSym 600i ABS Service Manual

1. General Information
1-1
Symbols and Marks ······················· 1-1
General Safety ······························ 1-2
Before Servicing ··························· 1-3
Specifications ······························· 1-9
Torque Values ······························· 1-10
Troubleshooting ···························· 1-12
Lubrication Points ························· 1-16
Symbols and Marks
Symbols and marks are used in this manual to indicate what and where the special service is needed. If
supplemental information is needed for these symbols and marks, explanations will be added in the text
instead of using the symbols or marks.
Warning
Means that serious injury or loss of life may happen if procedures are not
correctly followed.
Caution
Means that equipment damages may result if procedures are not followed.
Engine oil
Limits to use SAE 10W-30 API SG class oil. Warranty will not cover the
damage that caused by not apply with the limited engine oil.
(Recommended oil: KING MATE G-3 oil)
Grease
King Mate G-3 is recommended.
Locking sealant
Apply sealant; medium strength sealant should be used unless otherwise
specified.
Oil seal
Apply with lubricant.。
Renew
Replace with a new part before installation.
Brake fluid
Use recommended brake fluid DOT3 or WELLRUN brake fluid.
Special tools
Special tools
Correct
Meaning correct installation.
Wrong
Meaning wrong installation.
Indication
Indication of components.
Directions
Indicates position and operation directions
Components assembly directions each other.
Indicates where the bolt installation direction, --- means that bolt cross
through the component (invisibility).
