To this chapter contents
11. Steering / Front Wheel / Front Fork
11-12
Disassembly
Remove the brake disk (locknut×5).
Pull out the left side bearing and oil seal by
using the inner bearing puller.
Remove the distance collar.
Pull out the right side bearing and oil seal by
using the inner bearing puller.
Special tool：
Inner bearing puller SYM-6204020
Assembly
Install in the reverse order of removal.
Apply grease to the wheel hub / bearing
contact surface.
Install the left side bearing.
Install the distance collar and the right side
bearing.
Caution
z The bearing cannot lean to one side during
installation.
Nut×5
Bearing will be damaged in these
two examples of assembly.
Tool：
Bearing driver
To Next Page
